HK-1210

Compact Desktop Network System with MediaTek MT7622E (ARM A53) Dual-Core SoC

,
  • 1x MediaTek ARM MT7622E Processor (1.4GHz, 2 Cores)
  • 2GB DDR3L RAM
  • 2x GbE RJ45 Ethernet Ports
  • 1x Bypass 4.5
  • 1x Type C Console
  • 1x Wi-Fi Module (mPCIe)
Platform
Processor1 x MediaTek ARM MT7622E
Flash Memory128MB (NAND)
System Memory1 x DDR3L RAM (2GB on board)(Up to 2GB)
Ethernet Port2 x RJ45 GbE Port(s) on board
Bypass1 segment(s) on board
Expansion1x mPCIe (Wi-Fi, PCIe)
1x mPCIe (LTE, USB)
Storage Device1 x eMMC (4GB)
Power Supply24W Adapter
Dimension (WxDxH)110mm x 110mm x 26mm (4.4" x 4.4" x 1.04")
I/O
Management Console1 x Type C Console Port
USB Port1 x USB 3.0 Port(s)
Operation & Certifications
Operating EnvironmentTemperature: 0 - 40°C (32 - 104°F)
Storage EnvironmentTemperature: -5 - 50°C (23 - 122°F)
CertificationCE / FCC / RoHS
Models Core/Threads Frequency (Max) Cache TDP
MediaTek MT7622E2C1.4GHz

Order Inquiry

    HK-1210

    Desktop, 1 x MediaTek ARM (MT7622E), 1 x 2GB DDR3L RAM, 2 x RJ45 GbE (MT7531BE), 24W Adapter
